BECKER avionics

We are official dealer of the Becker Avionics, leading German producer of avionics with more than 50 years of experience.

BECKER is world leader in field of aircraft communication systems. Besides instruments for airliners, air traffic control and SAR they also produce avionics for small airplanes. The most interesting part of their offer are transponders and radio stations.

New radio station BECKER AR6201 are the followers of the legendary model AR4201. AR6201 is ideal for all, who are finding compact and affordable solution for prepared change to 8,33 kHz.

Inquire

Product list

There is offer from Becker Avionics for small airplanes, helicopters, gliders and microlight aircraft. Some instruments are produced in more than one variant:

 Radiostanice BECKER AR6201 AR6201 - in-built radio station  →  INQUIRE
- 25 kHz and 8,33 kHz, power 6 or 10 W, for booklet click here
- Monitoring of two frequencies, VOX/Intercom, diameter 57 mm
- We have finished and approved documentation for BECKER AR6201 for CESSNA, PIPER, ZLIN and others
Radiostanice RT6201

RT6201 - radio station without control panel  →  INQUIRE
- 25 kHz and 8,33 kHz, power 6 or 10 W, for booklet click here
- Monitoring of two frequencies, VOX/Intercom, diameter 57 mm
- Controlled by 1 or 2 panels RCU6201 (tandem seat concept)

Ovládací panel BECKER RCU6201 RCU6201 - radio station control panel  →  INQUIRE
- For radio station RT6201, diameter 57 mm, for booklet click here
- There is possibility of connection of 2 panels RCU6201
- Suitable also for AR6201 as secondary control (tandem seat concept)
Odpovídač sekundárního radaru BXP6403 BXP6403 - secondary radar transponder  →  INQUIRE
- S-mode, class 1, power 250 W, ADS-B output, for booklet click here
- For IFR and VFR below 50 000 ft, adjustable brightness
- Class 2 optional for IFR and VFR below 15 000 ft
- Panel width 160 mm, optional assembly frame instead of KT76A
Odpovídač BECKER BXP6401 BXP6401 - secondary radar transponder  → INQUIRE
- S-mode, class 1, power 250 W, ADS-B output, for booklet click here
- For IFR and VFR below 50 000 ft, adjustable brightness
- Compatible with A/C-mode in-built of BECKER ATC4401-1
- Optional S-mode, only class 2 or only A/C-mode
- Separated body from control panel optional

Default price list of Becker Avionics is possible to download below. Contact us for individual offer of instruments and assembly.

BECKER prefers sale, service and installation through certified maintenance centers. For this reason we are able to offer to you the best conditions for all aircraft types.

We can also help you with the correct sets, connectors, cables and other parts.

Files to download

Installation and connection

We are also specialized in approving and installations of TRIG avionics, including its combination with another instruments.

Properties and avionics connection

Radio stations BECKER have integrated intercom for 4 crew members, which can be turned on separately by button or by voice. All radio stations allow connection of two displays for parallel control in pillion seat aircraft.

S-mode transponders BECKER allows ELS/EHS/ADS-B and are ready to parallel or serial connection to blind height coders from different manufacturers. ICAO address a other information involved in S-mode are saved in separate module AM6400-1-(01) and they aren’t lost during transponder change.

Avionics from BECKER have EASA ETSO certification. Particular properties of individual variants can be different.

Documentation and in-built

BECKER avionics is suitable for airplanes, microlight airplanes, helicopters and gliders. We usually do complete change of cables and installation of modern equipment based on STC for certified aircraft. For modernization of equipment used for VFR traffic we use Minor Change. This procedure includes:

  • Procuring of suitable instrument including EASA FORM 1 certificate or FAA FORM 8130-3
  • Evaluation of need to change cables and antenna
  • Evaluation of need to airframe intervention (in-built to new or old hole)
  • Evaluation of weight and weight balance change
  • Working out of in-built documentation
  • Approving of in-built documentation for particular aircraft
  • Working out and approving of Aircraft manual supplement for particular aircraft
  • Assembly of new instrument
  • Change or repair of wiring
  • Test of new avionics including issue of certificate according to regulations
  • Release of aircraft into operation
  • Assistance to changing aircraft station certificate issued by Czech Telecommunication Office

Contact us for further information, particular solution and references.
